Self-powered compact timecode display

The BETSO TCD-1 is a compact timecode display with a large 1 inch high red LED screen. It automatically detects the incoming timecode format and starts displaying it as soon as an active timecode cable is connected, with zero frame offset.

Its internal Li-Ion accumulator provides up to 60 hours of operation, and external 9-16 V DC power can be used both to run the unit and recharge the battery.

Key features
- Compact self-powered timecode display
- Automatic SMPTE timecode format detection
- Zero frame input offset
- 1 inch high red LED display with adjustable brightness
- Menu-based settings
- Original LEMO and Hirose connectors
- Internal Li-Ion accumulator with charging circuit

Specifications
Display | 1 inch high red LED
Dimensions | 44.5 x 215 x 21 mm
Weight | Approx. 283 g including batteries
Powering | Internal Li-Ion accumulator
External powering | 9-16 V DC
Battery life | Up to 60 h
TC formats | 23.976-30 fps, DF/NDF, 0.5x and 2x multiples
Input sensitivity | 0.2-10 V p-p
